Galvanized Steel Ridge Cap Roll Forming Machine Hydraulic Control Glazed Tile Type

Galvanized Steel Ridge Cap Roll Forming Machine Hydraulic Control Glazed Tile Type
Galvanized Steel Ridge Cap Roll Forming Machine Hydraulic Control Glazed Tile Type Galvanized Steel Ridge Cap Roll Forming Machine Hydraulic Control Glazed Tile Type Galvanized Steel Ridge Cap Roll Forming Machine Hydraulic Control Glazed Tile Type Galvanized Steel Ridge Cap Roll Forming Machine Hydraulic Control Glazed Tile Type Galvanized Steel Ridge Cap Roll Forming Machine Hydraulic Control Glazed Tile Type

Duży Obraz :  Galvanized Steel Ridge Cap Roll Forming Machine Hydraulic Control Glazed Tile Type

Szczegóły Produktu:
Miejsce pochodzenia: Botou Hebei China
Nazwa handlowa: HC
Orzecznictwo: ISO/CE
Numer modelu: HC343
Zapłata:
Minimalne zamówienie: 1set
Cena: 13000-29000USD
Szczegóły pakowania: Main machine is nude,the computer control box is packed by carton box
Czas dostawy: 30days
Zasady płatności: 30% deposit by T/T in advance and 70% balance after inspection confirmation before shipment
Możliwość Supply: 20 sets/month

Galvanized Steel Ridge Cap Roll Forming Machine Hydraulic Control Glazed Tile Type

Opis
color: blue type: automatic
control system: PLC control cutting method: hydraulic cut
per month: 30 sets
High Light:

metal forming machines

,

cold roll forming equipment

Galvanized Steel Ridge Cap Roll Forming Machine Hydraulic Control Glazed Tile Type





Quick Detail:



1. Suitable to process: Color steel plate

2. Width of the plate: 400mm

3. Rollers: 15 rows

4. Dimensions: 8.1*1.35*1.51m

5. Power: 3+3kw

6. Rolling material: 45# steel(plated chrome on surface)

7. Thickness of the plate:0.3-0.6mm

8. Voltage: 380V 50Hz 3phases

9. Material of the cutting plate: Cr12

10. Hydraulic: 40#

11. Processing precision: Within 1.00mm

12. Control system: PLC control





Description:



Main parameter

No.

   Main parameter of Ridge Cap Roll Forming Machine

1

Suitable to process

Color steel plate

2

Width of the plate

400mm

3

Rollers

15rows

4

Dimensions

8100*1350*1510mm

5

Power

3+3kw

6

Rolling material

45# steel(plated chrome on surface)

6

Thickness of the plate

0.3-0.6mm

7

Productivity

4m/min

8

Diameter of the roller

Φ66 mm

9

Voltage

380V 50Hz 3phases

10

Material of the cutting plate

Cr12

11

Hydraulic

40#

12

Processing precision

Within 1.00mm

13

Control system

PLC control

Equipment components: Man-made uncoiler-roll forming machine-computer control system-hydraulic control system-press form-cutting





Application



This product is widely used in many kinds of industrial factory, civilian buildings, and Roof board for attached part product. It has advantage of pretty appearance, durable using and so on.





Competitive Advantage



1. save space

2. easy install

3. perfect service

4. excellent quality

5. save freight

Galvanized Steel Ridge Cap Roll Forming Machine Hydraulic Control Glazed Tile Type 0

Galvanized Steel Ridge Cap Roll Forming Machine Hydraulic Control Glazed Tile Type 1

Galvanized Steel Ridge Cap Roll Forming Machine Hydraulic Control Glazed Tile Type 2

Galvanized Steel Ridge Cap Roll Forming Machine Hydraulic Control Glazed Tile Type 3
